Recently, the manufacturing technology of carbon fiber composite pipes in China has been continuously upgraded. With the improvement of raw materials and optimization of forming processes, the application scale of carbon fiber pipes in sports equipment, medical equipment, industrial equipment, cultural and sports products and other fields has been continuously expanding. Compared with traditional metal pipes, carbon fiber pipes have outstanding advantages such as light weight, high strength, corrosion resistance, and high modulus, gradually replacing traditional components such as aluminum alloys and steel pipes, and driving the comprehensive improvement of downstream related product performance.

Carbon fiber tube is a high-performance component formed by compounding carbon fiber prepreg with epoxy resin matrix. The product performance largely depends on the entire process of laying, forming, curing, and post-treatment. At present, the mainstream production processes in China include four technical routes: coiling, winding, molding, and weaving forming. Different processes correspond to different usage scenarios, balancing cost and mechanical performance.

The coiling process is the most widely used processing method in the industry. During production, carbon fiber prepreg is precisely wrapped around the surface of the metal core mold according to the design angle, and the laying angle, number of layers, and tension are controlled by CNC equipment to ensure the radial and axial mechanical balance of the pipe. After the layer is laid, it is sent to a hot press tank to complete the resin curing under high temperature and pressure environment. This process has high production efficiency, smooth inner walls of pipes, stable dimensional accuracy, and is suitable for mass production of thin-walled circular pipe products such as billiard clubs, fishing rods, and telescopic rods.

The winding process uses continuous carbon fiber bundles to wrap the core mold according to a preset trajectory, which can flexibly adjust the circumferential and axial fiber arrangement. The pipe has excellent resistance to radial pressure and is commonly used for high-pressure pipe fittings and industrial support pipes. The weaving molding process weaves carbon fiber yarn into a tubular fabric and then impregnates it with glue for curing. The pipe has outstanding torsional resistance and stronger impact resistance, but the production cycle is long and it is mostly used for high-end customized components. The molding process is suitable for carbon fiber pipes with irregular cross-sections, relying on molds for shaping and ensuring good consistency in product dimensions, making it suitable for mass production of complex cross-section components.

Curing is a crucial step in determining the quality of carbon fiber tubes. Temperature, pressure, and insulation time need to be strictly matched, as a rapid heating rate can easily cause internal bubbles and delamination; Insufficient pressure can result in uneven resin distribution defects. After curing, slowly demold according to the gradient cooling to avoid bending and deformation of the pipe caused by temperature difference stress. After demolding, the pipes are cut, polished, and surface coated, and then subjected to size, straightness, and strength testing to remove defective products such as bubbles, cracks, and eccentricities.

In the past, high-end large-size and high-precision carbon fiber pipes relied on imports for a long time. With the iteration of domestic equipment, the bottleneck of raw materials and processes has been continuously broken. Domestic carbon fiber tube products not only significantly reduce procurement costs, but also allow customization of pipe diameter, wall thickness, and modulus parameters according to customer needs. Industry analysis indicates that with the release of downstream market demand, carbon fiber pipe manufacturing is developing towards high precision, low cost, and intelligence. Continuous optimization of future processes will further expand the application space of carbon fiber composite materials in more specialized fields.

In recent years, the popularity of billiards has continued to increase, and the pace of technological innovation in professional equipment has been accelerating. Compared to traditional solid wood billiard sticks that are prone to moisture deformation, uneven force transmission, and poor durability, carbon fiber billiard sticks have gradually become the preferred choice for professional events and high-end enthusiasts due to their core advantages of high strength, high stability, and low deflection. Relying on advanced composite material processing technology, the manufacturing process of domestically produced carbon fiber billiard clubs continues to iterate, reshaping industry quality standards with precision, standardization, and intelligent production.
High end carbon fiber billiard clubs often use aviation grade T700 PAN based carbon fiber as the core material. This material has excellent mechanical properties and strong chemical stability, making it the preferred substrate for high-performance sports equipment. The entire production process includes more than ten precision procedures, from raw material pretreatment to finished product quality inspection, with strict precision control throughout the entire process, building a foundation for high-quality products. In the early stage of production, the factory uses CNC cutting equipment to cut carbon fiber prepreg, with a cutting error controlled within 0.1 millimeters. At the same time, the fiber layer angle and tension are precisely regulated, with a tension error not exceeding ± 0.3N, ensuring uniform stress distribution of the rod structure.
The molding process is the core key to the quality of carbon fiber billiard sticks. The industry mainstream adopts vacuum assisted resin transfer molding technology, which completes injection molding under vacuum environment of -0.098 MPa and constant temperature conditions of 35 to 42 ℃. The constant pressure duration of 0.08 to 0.12 MPa is strictly controlled to stabilize the volume fraction of cured resin in the optimal range of 32% to 38%. At the same time, low-temperature plasma activation treatment technology is introduced to enhance the bonding force between fibers and resins through coupling agent modification, completely eliminating delamination and cracking problems. Some high-end styles use three-dimensional four-way weaving technology, combined with high-density inner cavity foam filling, to eliminate resonance echo of hollow carbon tube hitting the ball and restore the solid feeling of solid wood.
To ensure the accuracy of the rod body, an intelligent monitoring system is installed in the curing process, which monitors the deviation of six nodes of the rod body in real time through dual lasers and CMOS camera arrays, dynamically adjusts the temperature control area, and controls the straightness error of the rod body within 0.08 millimeters/meter. After molding, follow the principle of gradient slow cooling and cool down the mold at a rate not exceeding 2 ℃ per minute to avoid deformation caused by temperature differences. After rough grinding, fine grinding, and multiple polishing processes, the surface roughness is controlled within 0.8 μ m, balancing delicate hand feel and wear resistance.
Before leaving the factory, the finished product needs to undergo 108 comprehensive quality inspections, including straightness calibration, mechanical testing, temperature and humidity environment simulation, and weight testing, to achieve zero defect delivery of quality. With mature technology, the carbon fiber billiard club completely solves the problems of solid wood clubs being prone to moisture, bending, and high transmission loss. Its low deflection characteristics can accurately control and plug the hitting ball path, greatly improving handling stability.
Industry insiders say that with the continuous upgrading of composite material technology, carbon fiber billiard sticks will further balance lightweight, high strength, and high-quality playing experience, continuously promoting the development of billiard equipment towards specialization, high-end, and intelligence, and bringing better competitive experiences to sports enthusiasts.

Weihai Dongmeng Chengbang Import and Export Co., Ltd. is located in Huancui District, Weihai. It mainly engages in the research and production of carbon fiber pipes and carbon fiber billiard clubs, and has complete import and export qualifications. Relying on mature carbon fiber technology, we can provide customized carbon pipes and billiard club front and rear supports of various specifications, supporting OEM/ODM. Our products balance lightweight and stability, and are exported to domestic and foreign markets.
Development History of Weihai Dongmeng Chengbang Import and Export Co., Ltd
Based on the advantages of Weihai's local carbon fiber industry cluster, the team has been deeply involved in the research and development of carbon fiber pipes and carbon fiber billiard sticks for many years, accumulating mature production processes and overseas customer resources, and planning to build an import and export enterprise that integrates production and foreign trade.
The company was officially registered and established in Huancui District, Weihai, and settled in Zhangcun Town, Liandong U Valley Industrial Park. It has obtained complete qualifications for import and export of goods and technology, and mainly engages in the customization and export of high-performance carbon fiber composite materials, carbon fiber pipes, carbon fiber billiard clubs.
Integrate local carbon fiber production factory resources, build OEM/ODM customized production lines, covering various specifications of carbon pipes, front and rear support processing of billiard sticks; Simultaneously expanding overseas channels, our products focus on lightweight competitive billiard clubs and industrial carbon pipes, supplying to the European, American, and Southeast Asian markets, and steadily promoting the landing of foreign trade orders.

We will continue to deepen our cultivation in the field of carbon fiber sports equipment, optimize the process of billiard clubs, expand industrial carbon pipe matching orders, improve the domestic and international online and offline sales system, and create a benchmark enterprise for foreign trade of carbon fiber products in Weihai.
